Ubiquiti 2.35 - 2.55 GHz AirMax, 10dBi 2x2 MIMO Omni-Directional Antenna

Home // CCTV // Networking Equipment // Ubiquiti Networks // airMAX Antennas // Wireless Systems // Ubiquiti Networks // airMAX Antennas // Ubiquiti 2.35 - 2.55 GHz AirMax, 10dBi 2x2 MIMO Omni-Directional Antenna

Code: UB-AMO-2G10
Brand: Ubiquiti
Product Details
Ubiquiti 2.35 - 2.55 GHz AirMax, 10dBi 2x2 MIMO Omni-Directional Antenna

Overview
Specifications
Downloads

The first of its kind, airMAX Omni antennas deliver carrier-class, 2X2 dual-polarity, omni-directional MIMO performance. They are designed for seamless integration with Ubiquiti airMAX Rocket hardware.

Datasheets

UB-AMO-xG1x Datasheet.pdf

Dimensions: 1030 x 122 x 84 mm
Weight: 2.1 kg (Mount Included)
Frequency: 2.35 - 2.55 GHz
Gain: 10 dBi
Elevation Beamwidth: 12deg
Electrical Downtilt: 4deg
Max. VSWR: 1.7:1
Wind Survivability: 125 mph
Wind Loading: 14 lbf @ 100 mph
Polarization: Dual Linear
Cross-Pol Isolation: 25 dB Min.
ETSI Specification: EN 302 326 DN2
Mounting: Universal Pole Mount, RocketM Bracket, and Weatherproof RF Jumpers included
