Integriti Medium Powered Enclosure with 2 Amp PSU and Mounting Plate

The Inner Range Low Profile Metal Enclosures present a modular, application oriented solution to suit a variety of installation requirements. The three sizes of Low Profile Enclosures are designed to minimise necessary wall space and simplify the practice of selecting and installing enclosures. Powered and non-powered versions of each kind of enclosure are available. Four sizes of mounting plates enable many combinations of associated module PCB types to be installed within the same enclosure.

• Enclosures are constructed of medium duty, grey powder coated metal with a hinged removable lid
• A tamper switch and bracket are supplied with each enclosure
• Conduit access is provided by "punch out" holes in the top and bottom of the enclosure, while a DB9 mounting hole is also provided for the IR-995009 cable or similar
• Powered Low Profile Enclosures are designed to house the transformer, 2A Power Supply PCB, 7.0Ah Battery and one or more Module PCBs, depending on their size type
• 2A Power supply included

Datasheets

• IR-995201xx Datasheet.pdf

• Cabinet Dimensions: 460(L) x 358(W) x 85(D) (mm)
