7/0.25, 2x Twisted Pair, Individual Screened, Gel Filled Cable, Black, 500m Drum
CAB-RAD8723JF500
AVAILABLE TO ORDER
7/0.25, 2x Twisted Pair, Individual Screened, Gel Filled Cable, Black, 500m Drum
- Belden 8723 equivalent gel filled
- Conductors: Stranded 22 AWG 7 strands x 0.25mm tinned copper
- Insulation:0.26mm 75-degree Celsius polypropylene
- 1st pair colours: red & black
- 2nd pair colours: white & green
- Pair shielding: individual aluminium polyester laminate tape
- Construction: pairs cabled on common axis to reduce diameter
- Drain wire: 7 strands x 0.25mm tinned copper
- Jacket: polyethylene
- Jacket colour: black
- Jacket O/S: 5.63 mm
- Impedance: 45 Ohm
- Insulation resistance: 100 mega ohms between shields
- Working voltage: 50 volts between adjacent shields
No description available for this product
- Belden 8723 equivalent gel filled
- Conductors: Stranded 22 AWG 7 strands x 0.25mm tinned copper
- Insulation:0.26mm 75-degree Celsius polypropylene
- 1st pair colours: red & black
- 2nd pair colours: white & green
- Pair shielding: individual aluminium polyester laminate tape
- Construction: pairs cabled on common axis to reduce diameter
- Drain wire: 7 strands x 0.25mm tinned copper
- Jacket: polyethylene
- Jacket colour: black
- Jacket O/S: 5.63 mm
- Impedance: 45 Ohm
- Insulation resistance: 100 mega ohms between shields
- Working voltage: 50 volts between adjacent shields
