7/0.25, 2x Twisted Pair, Individual Screened, Gel Filled Cable, Black, 300m Drum

Home // Power & Cabling // Generic Cable // Underground Gel Filled Cable // 7/0.25, 2x Twisted Pair, Individual Screened, Gel Filled Cable, Black, 300m Drum
no-img
7/0.25, 2x Twisted Pair, Individual Screened, Gel Filled Cable, Black, 300m Drum



Code: CAB-RAD8723JF300
Brand: Generic
Product Details
7/0.25, 2x Twisted Pair, Individual Screened, Gel Filled Cable, Black, 300m Drum

  • Belden 8723 equivalent gel filled
  • Conductors: Stranded 22 AWG 7 strands x 0.25mm tinned copper
  • Insulation:0.26mm 75-degree Celsius polypropylene
  • 1st pair colours: red & black
  • 2nd pair colours: white & green
  • Pair shielding: individual aluminium polyester laminate tape
  • Construction: pairs cabled on common axis to reduce diameter
  • Drain wire: 7 strands x 0.25mm tinned copper
  • Jacket: polyethylene
  • Jacket colour: black
  • Jacket O/S: 5.63 mm
  • Impedance: 45 Ohm
  • Insulation resistance: 100 mega ohms between shields
  • Working voltage: 50 volts between adjacent shields
