AXIS PS56 Power Supply, 56V DC, 240W, 1.5A

AXIS-01726-001

AVAILABLE TO ORDER

AXIS PS56 Power Supply, 56V DC, 240W, 1.5A

Warehouse	Status
Seven Hills - NSW	AVAILABLE TO ORDER
Waterloo - NSW	AVAILABLE TO ORDER
Fyshwick - ACT	AVAILABLE TO ORDER
Loganholme - QLD	AVAILABLE TO ORDER
Dudley Park - SA	AVAILABLE TO ORDER
Tulla Central Warehouse- VIC	AVAILABLE TO ORDER
Mulgrave - VIC	AVAILABLE TO ORDER
Balcatta - WA	AVAILABLE TO ORDER
Canning Vale - WA	AVAILABLE TO ORDER

Overview

The AXIS-01726-001 is an industrial power supply with a compact design that has 100 to 240 V AC input voltage and delivers 240W.

Product specifics & Details

AC current consumption: 1.5 A at 230 V AC / 3 A at 115 V AC
AC input voltage range: 85-277 V AC (derating at 100 V AC)
DC current consumption: 1.5 A at 370 V DC / 3A at 120 V DC
DC input voltage range: 80-370 V DC
Input frequency: 45-65 Hz
Rated input voltage: 100-240 V AC (wide-range input)
Output power: 240 W
Output voltage: 56 V DC
Output voltage: 30-56 V (adjustable via potentiometer)
Operating conditions: -25 to 70 degrees celsius
Dimensions: H x D x W: 130 x 125 x 60mm
Weight: 1.05g
